DMF-50961NF-FW-AEN Kyocera 7.2INCH LCM 640×480RGB 90NITS CCFL INDUSTRIAL LCD DISPLAY

Product Categories
Sapientia Display Co.,LIMITED
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

DMF-50961NF-FW-AEN Kyocera 7.2INCH LCM 640×480RGB 90NITS CCFL INDUSTRIAL LCD DISPLAY

  • 1
  • 2
  • 3

Brand Name : Kyocera

Model Number : DMF-50961NF-FW-AEN

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/WESTERNUNION/ESCROW

Supply Ability : 50PCS

Delivery Time : 1-2day

Packaging Details : STANDARD PACKING

MODEL NUMBER : DMF-50961NF-FW-AEN

BRAND : Kyocera

SIZE : 7.2INCH

RESOLUTION : 640×480RGB

Luminance : 90 cd/m² (Typ.)

Interface Type : Parallel Data (4-bit) , 15 pins Connector

Type : FSTN-LCD, LCM

Environment : Operating Temperature: 0 ~ 50 °C

Contact Now

OPTREX DMF-50961NF-FW-AEN Application Features

Basic Information : Brand Name Model Name Type Model Alias
DMF-50961NF-FW-AEN FSTN-LCD , LCM -
Maximum Ratings : RoHS Operating Temperature Storage Temperature Vibration Level
0 ~ 50 °C -20 ~ 60 °C

OPTREX DMF-50961NF-FW-AEN Mechanical Features

Screen Size : 7.2"
Pixel Features : Pixel Number Pixel Format Dot Pitch (H×V) Pixel Pitch (H×V)
640×480, VGA Rectangle 0.23×0.23 mm 0.23×0.23 mm [110PPI]
Mechanical Size : Display Area (H×V) Bezel Opening (H×V) Overall Dimension (H×V) Overall Depth
147.18×110.38 mm 153.0×115.4 mm 205.5×141 mm 6.5 (Max.) mm
Outline Features : Form Shape Aspect Ratio (H:V) Orientation Shape Style
Flat Rectangle 4:3 Landscape type
Other Spec : Mass Panel Cover Surface Treatment
230g (Max.) - -
Holes & Brackets : Face mounting holes (4 pcs)

OPTREX DMF-50961NF-FW-AEN Optical Features

Basic Information : Luminance Work Mode Contrast Ratio
90 cd/m² (Typ.) STN, Black/White mode, Transmissive 12:1 (Typ.) (Transmissive)
Good View at Viewing Angle Response Time
6 o'clock - 270/140 (Typ.)(Tr/Td) (ms)
Dispaly Color : Color Temperature: Support Color Color Coordinate
- Monochrome

OPTREX DMF-50961NF-FW-AEN Electronics Features

Refresh Rate : 70Hz

OPTREX DMF-50961NF-FW-AEN Backlight Features

Back-light Features: Type Position Life(Hours) Amount Shape Replacement
CCFL Edge light type 10K(Min.) 1 pcs Straight -
CCFL Electrical : Input Voltage Input Current Power Consumption
315V (Typ.) 5.0±0.5mA
Operating Frequency Startup Voltage
420V (Min.)
Interface Features : CCFL Driver State Physical Type Interface Position
No Connector -
Interface Detail Brand Name Model Name Amount Pins Pin Pitch Pin Configuration
MITSUMI M63M83-04 1 pcs 4 pins 2.5 mm BLL-4PINS-LNNH

OPTREX DMF-50961NF-FW-AEN Interface Features

Signal Electrical : Input Voltage Input Current Power Consumption
5.0V (Typ.) 1.7/6.0mA (Typ./Max.) -
Interface Features : Signal Type Physical Type Interface Position
Parallel Data (4-bit) Connector -
Interface Detail : Brand Name Model Name Amount Pins Pin Pitch Pin Configuration
molex 53261-1590 1 pcs 15 pins 1.25 mm

FAQ:
Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
