25.0" 117PPI Industrial TFT Display 2560×1440 350cd/m2 LM250WQ3-SSA1

Name: 250quot 117PPI Industrial TFT Display 25601440 350cdm2 LM250WQ3SSA1
Brand: LG DISPLAY
Price: 1 USD

25.0" 117PPI Industrial TFT Display 2560×1440 350cd/m2 LM250WQ3-SSA1 Manufactures

Brand Name : LG DISPLAY

Model Number : LM250WQ3-SSA1

Certification : ISO9001

Place of Origin : JAPAN

MOQ : 1PCS

Payment Terms : TT/PAYPAL/ESCROW/WESTERN UNION

Supply Ability : 600PCS

Delivery Time : 1-2 DAYS

Packaging Details : STANDARD PACKING

MODEL NUMBER : LM250WQ3-SSA1

BRAND : LG DISPLAY

SIZE : 25.0 inch

BRIGHTNESS : 350CD/M2

Lamp Type : WLED

RESOLUTION : 2560(RGB)×1440 (Quad-HD) 117PPI

VIEWING ANGLEG : 89/89/89/89 (Typ.)(CR≥10)

TEMPERATURE RANGE : Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C

Contact Now

LG Display LM250WQ3-SSA1 Application Details

Basic Detail :	Manufacturer		Model Name	LM250WQ3-SSA1
	Panel Type	a-Si TFT-LCD , LCM	Another Name	LM250WQ3 (SS)(A1)
	Panel Size	25.0 inch	Designed For
Maximum Ratings :	OP Temperature	0 ~ 50 °C	ST Temperature	-20 ~ 60 °C

LG Display LM250WQ3-SSA1 Optical Details

Basic Information :	Luminance	350 cd/m² (Typ.)	Contrast Ratio	1000 : 1 (Typ.) (Transmissive)
	Good View at	Symmetry	Response Speed	14 (Typ.)(G to G) (ms)
	Viewing Angle	89/89/89/89 (Typ.)(CR≥10)	Operating Mode	AH-IPS, Normally Black, Transmissive
Color Performance :	Chromaticity	Wx:0.313; Wy:0.329	Support Color	16.7M (8-bit)
Color Performance :	Color Temperature	6485K	White Uniformity	1.33 (Max.)(9 points)
1931 Color Gamlt :	NTSC Ratio	77%	sRGB	100% coverage
	Adobe RGB	77% coverage	DCI-P3	80% coverage
	Rec.2020	57% coverage	Remarks	sRGB (Rec.709, BT.709), Rec.2020 (BT.2020)

LG Display LM250WQ3-SSA1 Mechanical Details

Pixel Features :	Number of Pixel	2560(RGB)×1440 [Quad-HD]	Arrangement	RGB Vertical Stripe
Pixel Features :	Dot Pitch(W×H)	0.0725×0.2160 mm	Pixel Pitch(W×H)	0.2160×0.2160 mm [117PPI]
Physical Size :	Active Viewing	552.96(W)×311.04(H) mm	Overall Dim.	565(W)×324.1(H) mm
Physical Size :	Bezel Opening	-	Overall Depth	9.05/13.2 (Typ./Max.) mm
Outline Features :	Form Shape	Flat Rectangle	Orientation	Landscape type
Outline Features :	Aspect Ratio(W:H)	16:9	Shape Style	4-side borderless
Fixation :	Rear mounting holes
Other Detail :	Mass	1.99/2.09Kgs (Typ./Max.)	Surface	Antiglare, Hard coating (3H)

LG Display LM250WQ3-SSA1 Interface Details

Signal Electrical :	Input Current	0.41/0.51A (Typ./Max.)		Input Voltage	10.0V (Typ.)
Signal Electrical :	Consumption	4.1/5.13W (Typ./Max.)	Signal Interface	LVDS (4 ch, 8-bit)
Interface Features :	Position		Physical Type	Connector
Signal Interface :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
Signal Interface :	HRS	KN38B-30S-0.5H	1 pcs	0.5 mm	30 pins

LG Display LM250WQ3-SSA1 Lightting Details

Lamp Features:	Lamp Shape	-	Lamp Type	WLED	Position	Edge light type (Bottom side)
Lamp Features:	Exchange	-	Amount	-	Life	30K(Min.) (Hours)
Lamp Electrical :	Input Current	90/95mA (Typ./Max.)		Input Voltage	26.3±1.8V
Lamp Electrical :	Consumption	18.9W (Typ.)
Interface Features :	Position		Physical Type	Connector
Interface Detail :	Brand	Model	Amount	Pin Pitch	Pin Amount	Pin Assignment
Interface Detail :	JST	BM06B-SHJS-TB(HF)	2 pcs	1.0 mm	6 pins	BLE-6PINS-CCAACC
Backlight Driver :	No

LG Display LM250WQ3-SSA1 Packing Details

Package Box :	Amount	Size (L×W×H)	Weight
Package Box :	10 pcs / box	365×710×448 mm	-

Q1: What's the quality of your LCD Panel?
A: Various quality such as 100% New & Original OEM New, A Grade LCD, A- LCD Panel etc.
Q2: What is your return and refund policy?
A: We provide you excellent after-sales services, and promise you 6-month warranty after shipping to assure you a stable performance.
Q3: How long is the lead time?
A: The lead time is about 1-3 working days after receipt of payment.
Q4: How can I get the quotation?
A: Please enquire via Skype,Email,Whatsapp or telephone. You will get reply within 24 hours.
